Throttle Body for Forklift
Forklift Throttle Body - The throttle body is part of the intake control system in fuel injected engines in order to regulate the amount of air flow to the engine. This mechanism operates by placing pressure upon the driver accelerator pedal input. Normally, the throttle body is situated between the air filter box and the intake manifold. It is usually attached to or positioned close to the mass airflow sensor. The largest part within the throttle body is a butterfly valve known as the throttle plate. The throttle plate's main task is so as to control air flow.
On nearly all vehicles, the accelerator pedal motion is transferred via the throttle cable, thus activating the throttle linkages works to be able to move the throttle plate. In cars consisting of electronic throttle control, otherwise called "drive-by-wire" an electric motor controls the throttle linkages. The accelerator pedal is attached to a sensor and not to the throttle body. This particular sensor sends the pedal position to the ECU or also known as Engine Control Unit. The ECU is responsible for determining the throttle opening based on accelerator pedal position together with inputs from various engine sensors. The throttle body consists of a throttle position sensor. The throttle cable connects to the black portion on the left hand side which is curved in design. The copper coil located next to this is what returns the throttle body to its idle position when the pedal is released.
The throttle plate rotates in the throttle body each time the operator presses on the accelerator pedal. This opens the throttle passage and enables much more air to flow into the intake manifold. Usually, an airflow sensor measures this change and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors so as to produce the desired air-fuel ratio. Generally a throttle position sensor or TPS is connected to the shaft of the throttle plate so as to provide the ECU with information on whether the throttle is in the wide-open throttle or likewise called "WOT" position, the idle position or somewhere in between these two extremes.
Several throttle bodies could have adjustments and valves to be able to regulate the minimum airflow during the idle period. Even in units which are not "drive-by-wire" there will often be a small electric motor driven valve, the Idle Air Control Valve or otherwise called IACV that the ECU utilizes so as to control the amount of air that could bypass the main throttle opening.
In lots of vehicles it is common for them to have a single throttle body. So as to improve throttle response, more than one could be used and attached together by linkages. High performance cars like for example the BMW M1, along with high performance motorcycles like for instance the Suzuki Hayabusa have a separate throttle body for each cylinder. These models are called ITBs or otherwise known as "individual throttle bodies."
A throttle body is like the carburetor in a non-injected engine. Carburetors combine the functionality of the fuel injectors and the throttle body into one. They operate by combining the air and fuel together and by controlling the amount of air flow. Automobiles that have throttle body injection, which is referred to as CFI by Ford and TBI by GM, situate the fuel injectors in the throttle body. This enables an older engine the possibility to be converted from carburetor to fuel injection without significantly altering the engine design.
